Libere el potencial del 400G con el sistema de línea modular

Bienvenido a la nueva era del transporte a 400G y de la interconexión de centros de datos con los módulos revolucionarios 400G ZR y Open ZR+. Estas innovaciones han desbloqueado el potencial de las ópticas DWDM plugables abiertas, permitiendo servicios IP transparentes sobre DWDM e interconexiones de centros de datos. Prepárese para adoptar el sistema de línea modular de Skylane Optics, especialmente diseñado para simplificar sus despliegues DCI. Nuestra solución totalmente modular combina la conveniencia de los amplificadores ópticos plugables, disponibles en formatos QSFP-DD Dual Pluggable o QSFP Pluggable, con un divisor de potencia óptica de 8 canales y un adaptador de estacionamiento LC fácil de usar. Descubra el sistema de línea modular avanzado de Skylane Optics y optimice sin esfuerzo sus despliegues DCI e IP-over-DWDM. Viva el futuro de las redes de alta velocidad con facilidad y eficiencia.

Sistema de línea modular 400G

QSFP-DD Dual Pluggable EDFA

Product SKU	Product description
Q2F15D14000D000	QSFP-DD Dual Pluggable EDFA Booster amplifier for DWDM, Duplex LC, Input power -20dBm to 0dBm, Nominal gain +20dB
Q2F15D14000DAD6	Cisco® Compatible QSFP-DD Dual Pluggable EDFA Booster amplifier for DWDM, Duplex LC, Input power -20dBm to 0dBm, Nominal gain +20dB
Q2F15D14000DC3L	Juniper Networks® Compatible QSFP-DD Dual Pluggable EDFA Booster amplifier for DWDM, Duplex LC, Nominal gain +20dB

Features & Benefits:

• Cost-effective solution that offers amplification for QSFP-DD ZR and Open ZR+.
• Only pluggable EDFA that provides LC connectors for both input and output.
• Supports up to 8 channels with 120km ZR and Open ZR+ capabilities.
• Combines both boost and pre-amp amplifiers in a single pluggable device.
• Ideal for lower density point to point deployments.

---

QSFP-DD Pluggable EDFA

Product SKU	Product description
Q2E15G17000DAEC	QSFP28 Pluggable EDFA QSFP28 Booster amplifier for DWDM, Tx side, duplex LC, Input power -20dbm to 0dbm, Nominal gain 17db
Q2E15A17000DAED	QSFP28 Pluggable EDFA QSFP28 preamplifier for DWDM, Tx side, duplex LC, Input power -30dbm to -10dbm, Nominal gain 17db

Features & Benefits:

• Adjustable output power of up to +17dBm.
• Operating temperature range: 0°C to 70°C.
• Compact footprint with open line system functionality.
• Integration into existing ROADM platforms without the need for additional rack space.
• Embedded gain flattened-filter (GFF) and individual boost & pre-amp options over maximum flexibility

---

Colorless Splitter 2 1×8

Product SKU	Product description
SK-2X1XLC8XLCPLC1MSM	Dual Colorless Splitter, Duplex 1×8 PLC Splitter, Duplex LC connectors, 1M, SMF

Features & Benefits:

• Supports up to eight channels.
• Operating wavelength: 1260nm to 1650nm.
• Withstands industrial temperatures of -40°C to 85°C.

---

QSFP LC Parking Adapter

Product SKU	Product description
SKY-PLG-QSF-12	QSFP Parking Adapter, LC or MPO Connector Compatibility Duplex/Simplex w/Dust Covers, 12 Piece

Features & Benefits:

• Streamlines access for swift turnup of future services.
• Facilitates secure and efficient management of loose duplex LC connectors

Experience the future of high-speed networking with ease and efficiency thanks to our modular line system! Contact us┃Skylane Optics !
